Embedded Wi-Fi, BT Modules architechture image

Low power, high performance Embedded - EM series modules are targeted for Wi-Fi connectivity to embedded devices by reducing the complexity of development for the end user. These Embedded wireless modules comes as plug and play devices by integrating all the necessary wireless hardware and software into a small form factor module which can be driven by a simple microcontroller. These embedded architecture modules come with a real time operating system, fully integrated TCP/IP (Network) stack, wireless stack and security supplicants inside the device to make it fully self contained serial to wireless module solution. This architecture reduces the complexity for the designer's approach on building products with out even knowing about wireless (WLAN) protocol and RF design. A major advantage with this Architecture is short time-to-market, low-power and reduced cost for the end system.

Ultra-Low Power Modules

Ultra Low Power

embedded/intergated TCP/IP Networking Stack Modules

Integrated TCP/IP (Network) Stack

High Throughput (datarate) Modules

High Speed data

integrated/embedded antenna modules

Integrated antenna

ultra small modules

Small form factor

These Microcontroller based Wireless (Wi-Fi) Modules and subsystems can give very high wifi throughputs. These embedded modules comes with complete IEEE 802.11 b/g/n standards and supports WiFi Station or wifi client, Access Point & Wi-Fi Direct modes with various stadard security protocols WPA, WPA2, WPS, WEP and Enterprise security providing wireless interface to any device. These modules come with USB, SPI and UART interfaces and option to select with or without antenna and a MHF4 IPEX connector for external antenna. These fully certified (FCC, IC, CE) wireless modules supporting single-band (802.11bgn) enables variety of applications in Medical, Home Automation, Internet of Things (IoT), Industrial IoT (IIoT) and Machine to Machine (M2M) markets. These fully-integrated solutions can be used for various embedded wireless applications. These industrial wireless modules support the full operating temperature range of -40 to +85 degrees. These ultra small form factor embedded wireless modules are easily portable to any low-cost, low-power MCU platforms.

Module Protocols Antenna Dimensions Certification

WE935B00

802.11 b/g/n 20MHz On board Chip antenna + MHF4 IPEX connector 15 mm x 16.5 mm x 1.86 mm On going
